POST DRIVING WITH POWER
















Revolutionize your fencing procedures with the air driven Picket Post Driver. Designed & manufactured in Australia. This air tool has proven its worth in the harsh terrain of many different areas around Australia,
New Zealand, UK, South Africa, Canada and now the USA.

• Build long stretches of fences in record time.
• Drive T posts through shale, black soil surfaces, rocky ground, ironstone and caliche rock.
• Adaptable to drive a variety of other steel, wood and fiberglass posts.
• Comparable tools cost thousands more than our Picket Post Driver.


This air tool has been proven on the harsh terrain of Central Australia building long strained fencing in record time. It will drive T posts through shale, black soil surfaces, rocky ground, ironstone and caliche rock.

It is easily dismantled for servicing and replacing the striking dolly.
Drives T Posts and Trellising Posts with ease. Also drives trellising posts, plastic posts, timber stakes, 2″, 3″ and 4″ round or square wood posts.




























INFORMATION ON DRIVERS & SPARE PARTS

Driver comes with:
• Standard 54mm guide
• Striking dolly in the driver
• Quick release coupling & hose clamp to connect hose to driver
• 12mm brass tail & hose clamp to connect hose to compressor

• Spare grub screws, lock nuts & allen key
To drive 2 " to 4 " water pipe a high tensile plug must be used in the top of the pipe and then transferred to the next pipe. Also drives roadside guide posts. (Included in Drive Kits)

STRIKING DOLLY - There is 1 dolly in the box with the driver. A dolly will fatigue between 5,000 to 15,000 posts depending on the type of ground and how the driver is used. Farmers will probably never need another dolly   while contractors will break them after continual use. It is advisable to always have a spare dolly so you can continue to use the   driver if you break a dolly.

ADAPTOR DOLLY - The adaptor dolly has a 25mm hole with 6 sets of grub screws to hold any tool you want to make up yourself. This could be a ramming bar, bead breaker, rock breaker, chisel, flat faced tamper for compacting mud brick and earthen walls etc. To use   the adaptor dolly firstly remove the guide then unscrew the retaining nut and replace the striking dolly with the adaptor dolly.   Do not replace the guide. Anti-seize grease needs to be used on the shank of the tool.

CHISELS - Chisels are 1150mm long and fit directly into the driver. Anti-seize grease MUST be used on the shank of the tool.

PICK - Picks are 1150mm long and fit directly into the driver. Anti-seize grease MUST be used on the shank of the tool.

BEAD BREAKER - 38mm long and fit directly into the driver. Anti-seize grease MUST be used on the shank of the tool.

GUIDE POST DRIVE KITS - Drive kits are available for Dura-Post, Ezy-Drive and Smart posts. Other sized drive kits can be made to your needs.

GUIDES - The standard guide supplied is 54mm.Additional guides are available from 56mm to 145mm bore.

PLUGS TO SUIT - 2.375", 2.875" ", 3.5 ", and 4" pipe. To be placed in the top of the pipe and then transferred to the next pipe.

Power Post Driver
